Master Cylinder

This master cylinder still works when pumped but it could do with new seals being fitted





This Master Cylinder below has been knocking around for a while in my shed, its missing almost everything with the exception of the inner parts.

Its nice and shiny as its just come out of the parts washer.





New Master Cylinders can still be bought off E-bay for approximately £60. The only differences as far as I can see is that it does not come with the extension tube but it does come with an extra bleed nipple on the master cylinder body.





Having had a look inside the filler hole it would be advisable to clean the preservative from inside before use and it might also be worthwhile replacing the seals as well.





Wheel Cylinders

Brake pipe banjo unions, to the left in the picture below front type and to the right the rear type of banjo (two studs).

Steel or Copper Brake pipe lengths inside the Ferret hull

From the Left hand side rear elbow approx 94 inches long

From the Right hand side rear elbow approx 98 inches long

Connection pipe from left side to master cylinder inches ** long

Flexible Brake pipes lengths

Front

Rear

Brake Servo

Lockheed HA1 Remote Vacuum Servo can still be obtained new EBay is a good place to find one.

Brake servo with the correct brake pipes.
